Unique Features

The 2019 model year Apache Sprayers build upon recent innovations to deliver even more of the performance and value producers have to come to expect. The 2019 lineup features new components that improve machine durability, longevity, operator convenience and comfort, all while keeping the sprayers up to 33% lighter than competing sprayers. It means the new Apache Sprayers — and their operators — will be able to work longer, smarter and more efficiently in the field.



AS640

AS740

AS1040

AS1240

TANK CAPACITY 650 gal 750 gal 1,000 gal 1,200 gal
CHASSIS, SUSPENSION & TIRES
WEIGHT
(APPROXIMATE DRY WEIGHT)
16,900 lbs 19,700 lbs 20,000 lbs 21,000 lbs
AXLE WIDTH 88″, 90″, 108″ or 120″ fixed 120″ fixed 120″-160″ adjustable (with optional 50″ clearance only) 120″ fixed 120″-160″ adjustable (with optional 50″ clearance only) 120″ fixed 120″-160″ adjustable (with optional 50″ clearance only)
TRANSPORT WIDTH & HEIGHT 144″ maximum 144″ maximum 144″ maximum 144″ maximum
OVERALL LENGTH 290″ maximum 290″ maximum 290″ maximum 290″ maximum
TURNING RADIUS 17’2″ 18′ 18′” 18′
WHEEL BASE 13″8′ 15′ 15′ 15′
FRONT TIRES (STANDARD) Michelin 380/85R34 Michelin 380/80R38 Michelin 380/80R38 Michelin 380/80R38
REAR TIRES (STANDARD) Michelin 380/80R38 Michelin 380/90R46 Michelin 380/90R46 Michelin 380/90R46
CROP CLEARANCE 42″ or 48″ based on tire selection with JCB final drives JCB 42″ with planetary final drive 50″ with 18″ drop box all-gear final drives (optional) JCB 42″ with planetary final drive 50″ with 18″ drop box all-gear final drives (optional) 50″ with 18″ drop box all-gear final drives
SPRAY OPTIONS
BOOMS ET Custom Boom (Steel) Straight 90′ or 60’/90′

Pommier (Aluminum) Straight 100′

ET Custom Boom (Steel) Straight 90′, 100′ or 60’/90′

Pommier (Aluminum) Straight 100′,120′ or 132′

ET Custom Boom (Steel) Straight 90′, 100′ or 60’/90′

Pommier (Aluminum) Straight 100′,120′ or 132′

ET Custom Boom (Steel) Straight 90′, 100′ or 60’/90′

Pommier (Aluminum) Straight 100′,120′ or 132′

RINSE TANK 50 gal 90 gal 90 gal 90 gal
ENGINE & DRIVETRAIN
RATED HORSEPOWER 163 hp 173 hp 225 hp 260 hp
DRIVELINE EFFICIENCY 90% 90% 90% 90%
PTG: HP PER 1,000 lbs. 8.7 7.9 10.1 11.1
FUEL TANK CAPACITY 80 gal 90 gal 90 gal 90 gal
SUSPENSION Active airbag with independent front Patented independent hydraulic Patented independent hydraulic Patented independent hydraulic
TOP ROAD SPEED 32 mph 30 mph 35 mph 35 mph
TRANSMISSION JCB transmission Powershift, 4-speed JCB transmission Powershift, 4-speed ZF Powershift, 6-speed with lock-up torque converter ZF Powershift, 6-speed with lock-up torque converter
ENGINE Cummins Tier 4F 163 hp (rated) Cummins Tier 4F 173 hp (rated) Cummins Tier 4F 225 hp (rated) Cummins Tier 4F 260 hp (rated)

RAVEN AND TRIMBLE PRECISION APPLICATION EQUIPMENT IS AVAILABLE FACTORY INSTALLED ON ALL NEW APACHES. Click here for detailed options.
