AS1250 and AS1250XP Sprayers

AS1250 and AS1250XP Sprayers

The Apache AS1250 and AS1250XP sprayers are the largest in the AS family, yet they weigh far less than the competition. The XP model features added horsepower and is adaptable to ensure it meets all of your spraying needs.

The Apache Sprayers XP package provides the ideal combination of power, traction, and efficiency, along with the simplicity of a mechanical drive transmission. Additionally, you’ll get the same superior fuel economy and state-of-the-art precision options you would in any of the other Apache models.

AS1250 Features

Product Tank Capacity: 1,200 gal
Weight: 21,200 lbs
Crop Clearance: 50″ with 18″ Drop Box All-Gear Final Drives
Engine: Cummins Performance
AS 1250: Series V, 260 hp (rated)
AS1250XP Cummins Performance Series V, 300 hp (rated)
Optional: Stainless steel tank



Apache Sprayers Cost Less, Weigh Less and Deliver MORE

With our lightweight Apache Sprayers you can spray for as little as $3 an acre– reducing soil compaction, increasing crop yields, and generating impressive ROI. From our industry-best, 5-year warranty, to being the only 4-time winner of the “Highest Retained Value” award by EquipmentWatch™, we are the best self-propelled on the market.

AS1250 XP

Power, performance, and value- that is what you can expect from Apache Sprayers.

Equipment Technologies

MY2022 New AS1250 Product Enhancements

Improved Operator Ride

Enjoy a more comfortable ride. Our fluid-elastic active “Hydrocone” cab isolators from AMC Mecanocaucho improve the ride as much as 50% by better absorbing shock and displacement of the chassis.

Ease of Steering

Our new variable displacement load-sense piston pump provides the right amount of hydraulic flow at all speeds while reducing steering effort by as much as 20% for ease of steering at headlands, hills and tight corners.

Boom Recirculation

Helps in priming the boom before spraying, ensuring a precise and uniform spray pattern. It also reduces and/or eliminates product settling in boom pipes, enables accessible and complete cleanout of the booms, detects spray mode vs. recirculation mode automatically, and works with different precision options such as individual nozzle control, section control, etc. with built-in low-flow alert.



Request a free field demo and find out why EquipmentWATCH ranks Apache Sprayers Highest Retained Value in the industry, or determine the lifetime value of owning an Apache with our NEW total cost of ownership tool.

AS1250 & 1250XP Options

Our sprayers are reliable for many reasons, one being our lean manufacturing to build sprayers exactly the way you want them. That means we don’t force you to pay for the things you don’t want or need. Our “a la carte” menu gives you the freedom to choose upgrades, so your sprayer is customized for you and your operational needs.

OptionDescription
Extra Power with XPThe XP package from Apache Sprayers provides the perfect
combination of power, traction and efficiency, along with the simplicity of a mechanical drive transmission.
Stainless Steel The all-new 1200-gallon stainless steel product tank features a redesigned baffle, tank agitation, tank rinse, sump, sight gauge, and tank mounts.
Fence-Row NozzlesThese added nozzles are great for keeping fence lines and
outer edges of fields clean. The extra nozzle can be added to the left or right side of the boom, or both.
3-Inch Product FillFill up faster thanks to the upgraded 3-inch diameter
product fill connection.
Hypro® Cleanload™The Hypro Cleanload is a self contained eductor system that allows operators to mix liquid and dry chemicals safely and quickly.
FendersIf you want mud splash-back protection, fenders are a great option to help keep things clean and prevent dust and mud clogs. Available in the front, rear, or a combination of each.
Enhanced Lighting PackageOur optional LED lighting package produces more light, while consuming less energy. This lighting package features 64 LED bulbs, located above the grille and cab and next to the fill station. The lights are situated to reduce bounceback reflection. LED bulbs have an average lifespan of tens of thousands of hours.
Power MirrorsOperators have the option of adjusting the single power side mirror attached to the cab from within the cab.

AS1250 & AS1250XP Virtual Tour

Schedule your FREE Apache field demo and get a no-obligation sales quote.








Unique Features of the AS1250/1250XP

  TANK CAPACITY
Standard Poly Tank or
NEW Stainless Steel Upgrade
1,200 gal

CHASSIS, SUSPENSION & TIRES
WEIGHT
(APPROXIMATE DRY WEIGHT)
21,200 lbs
AXLE WIDTH

120″ fixed or 120″-160″ hydraulic adjustable

TRANSPORT WIDTH & HEIGHT 144″ maximum
OVERALL LENGTH 290″ minimum
TURNING RADIUS 20′
WHEEL BASE 15′
FRONT TIRES (STANDARD) Michelin 380/80R38
REAR TIRES (STANDARD) Michelin 380/90R46
CROP CLEARANCE 50″
SPRAY OPTIONS
BOOMS

90′, 60/90′, 100′ steel or Pommier 100′, 120′, or 132′ aluminum

RINSE TANK 100 gal
ENGINE & DRIVETRAIN
RATED HORSEPOWER 260HP or 300HP optional
DRIVELINE EFFICIENCY 90%
PTG: HP PER 1,000 lbs. 11 (12.7 with 300HP)
FUEL TANK CAPACITY 90 gal
TRANSMISSION ZF power shift 6 speed
ENGINE
Cummins Performance Series V



Want more? Download the full spec sheet.
