AS850 Sprayer

Apache Sprayers AS850

An ideal balance between our compact and large capacity-sized sprayers, the AS850 features an 800-gallon spray tank and a Cummins B4.5 Performance Series engine, so you won’t have to compromise spray capacity and reliability.

Noise Dampening Comfort Cab

Just like all Apache Sprayers, the AS850 is fuel-efficient, reliable, and provides leading operator comfort with state-of-the-art noise dampening inside the cab, a positive-position joystick and Bluetooth ® capabilities.

Ease of Steering

The variable displacement load-sense piston pump provides the right amount of hydraulic flow at all speeds while reducing steering effort by as much as 20% for ease of steering at headlands, hills and tight corners.

Get more information
and your free, no-obligation sales quote.

AS850 Features

Product Tank Capacity: 800 gallons
Weight: 18,400 lbs
Engine: Cummins B4.5 Performance Series 200HP (rated)
Transmission: JCB Powershift 4-Speed
Crop Clearance: 42″ with JCB planetary final drive or 50″ with 18″ drop box all-gear final drives

“Apache Sprayers are simple in design, well balanced, lightweight, and they keep making them better year after year.

— Mike Wolford, Ohio

AS850 Standard Features

Improved Operator Ride

Enjoy a more comfortable ride. Our fluid-elastic active “Hydrocone” cab isolators from AMC Mecanocaucho improve the ride as much as 50% by better absorbing shock and displacement of the chassis.

Ease of Steering

Our new variable displacement load-sense piston pump provides the right amount of hydraulic flow at all speeds while reducing steering effort by as much as 20% for ease of steering at headlands, hills and tight corners.

Boom Recirculation

Helps in priming the boom before spraying, ensuring a precise and uniform spray pattern. It also reduces and/or eliminates product settling in boom pipes, enables accessible and complete cleanout of the booms, detects spray mode vs. recirculation mode automatically, and works with different precision options such as individual nozzle control, section control, etc. with built-in low-flow alert.

Additional AS850 Specifications

Axle Width: 120″

Tires: Michelin 380/80R38 front, Michelin 380/90R46 rear

Product Tank: HDPE, high-density polyethylene

Cab: Leather seat with heating and cooling

Warranty: 2-year bumper to bumper and 5-year limited warranty

Contact us and find out why EquipmentWATCH ranks Apache Sprayers Highest Retained Value in the industry, or determine the lifetime value of owning an Apache with our NEW total cost of ownership tool.

AS850 Options

Our sprayers are reliable for many reasons, one being our lean manufacturing to build sprayers exactly the way you want them. That means we don’t force you to pay for the things you don’t want or need. Our “a la carte” menu gives you the freedom to choose upgrades, so your sprayer is customized for you and your operational needs.

Option
Description
Fence-Row NozzlesThese added nozzles are great for keeping fence lines and
outer edges of fields clean. The extra nozzle can be added to the left or right side of the boom, or both.
3-Inch Product FillFill up faster thanks to the upgraded 3-inch diameter
product fill connection.
Hypro® Cleanload™The Hypro Cleanload is a self contained eductor system that allows operators to mix liquid and dry chemicals safely and quickly.
Power MirrorsOperators have the option of adjusting the single power side mirror attached to the cab from within the cab.

Schedule your FREE Apache field demo and get a no-obligation sales quote.

Want more information?

AS850 Model Specifications

Unique Features of the AS850

  TANK CAPACITY

800 gal

CHASSIS, SUSPENSION & TIRES
WEIGHT
(APPROXIMATE DRY WEIGHT)
18,400 lbs
AXLE WIDTH 120″ fixed or 120″-160″ hydraulic adjustable (optional with 50″ crop clearance only)

TRANSPORT WIDTH & HEIGHT 144″ maximum
OVERALL LENGTH 290″ minimum
TURNING RADIUS 20′
WHEEL BASE 15′
FRONT TIRES (STANDARD) Michelin 380/80R38
REAR TIRES (STANDARD) Michelin 380/90R46
CROP CLEARANCE 42″ standard or 50″ optional
SPRAY OPTIONS
BOOMS

90′, 60/90′, 100′ steel or Pommier 100′, 120′, or 132′ aluminum

RINSE TANK

100 gal

ENGINE & DRIVETRAIN
RATED HORSEPOWER 200 HP
DRIVELINE EFFICIENCY 90%
PTG: HP PER 1,000 lbs. 8.9
FUEL TANK CAPACITY 90 gal
TRANSMISSION JCB powershift 4-speed
ENGINE Cummins B4.5 Performance Series 200HP (rated)
