AS650 Sprayer

Apache Sprayers AS650

Rugged, nimble, and built to go where others won’t dare. The new AS650 is one tough sprayer with comfort and upgrades to spare. Model-year 2022 innovations include an improved operator ride, enhanced steering, and a new boom recirculation system.

Uncompromising capability and elevated performance are the hallmarks of the new AS650. Engineered with a 164” short wheelbase, the AS650 has a turning radius of 17 feet to help operators maneuver in tight turnarounds and narrow roads. The AS650 is compact, lightweight, and agile — and the best small self-propelled sprayer in the industry.

Get more information
and your free, no-obligation sales quote.

AS650 Features

Product Tank Capacity: 650 gallons
Weight: 16,900 lbs
Engine: Cummins T4F
Transmission: JCB Powershift 4- speed
Crop Clearance: 42″ or 48″ depending on tire selection

Power, performance, and value- that is what you can expect from the AS650, the best small farm sprayer in the industry.

Equipment Technologies

New MY2022 AS650 Product Enhancements

Improved Operator Ride

Enjoy a more comfortable ride. Our fluid-elastic active “Hydrocone” cab isolators from AMC Mecanocaucho improve the ride as much as 50% by better absorbing shock and displacement of the chassis.

Ease of Steering

Our new variable displacement load-sense piston pump provides the right amount of hydraulic flow at all speeds while reducing steering effort by as much as 20% for ease of steering at headlands, hills, and tight corners.

Boom Recirculation

Helps in priming the boom before spraying, ensuring a precise and uniform spray pattern. It also reduces and/or eliminates product settling in boom pipes, enables accessible and complete cleanout of the booms, detects spray mode vs. recirculation mode automatically, and works with different precision options such as individual nozzle control, section control, etc. with built-in low-flow alert.

Request a free field demo and find out why EquipmentWATCH ranks Apache Sprayers Highest Retained Value in the industry, or calculate your total cost of ownership to determine the lifetime value of owning an Apache Sprayer.

AS650 Options

Our sprayers are reliable for many reasons, one being our lean manufacturing to build sprayers exactly the way you want them. That means we don’t force you to pay for the things you don’t want or need. Our “a la carte” menu gives you the freedom to choose upgrades, so your sprayer is customized for you and your operational needs.

Option
Description
Premium Cab UpdateThe new Premium Cab upgrade, exclusively for the AS650, includes a heated and cool option for the leather seat, high output lighting, power mirrors, XM radio, and a premium trim package inside the cab.
Fence-Row NozzlesThese added nozzles are great for keeping fence lines and outer edges of fields clean. The extra nozzle can be added to the left or right side of the boom, or both.
3-Inch Product FillFill up faster thanks to the upgraded 3-inch diameter
product fill connection.
Hypro® Cleanload™The Hypro Cleanload is a self-contained eductor system that allows operators to mix liquid and dry chemicals safely and quickly.
FendersIf you want mud splash-back protection, fenders are a great option to help keep things clean and prevent dust and mud clogs. Available in the front, rear, or a combination of each.
Enhanced Lighting PackageOur optional LED lighting package produces more light while consuming less energy. This lighting package features 64 LED bulbs, located above the grille and cab and next to the fill station. The lights are situated to reduce bounceback reflection. LED bulbs have an average lifespan of tens of thousands of hours

AS650 Virtual Tour

Schedule your FREE Apache field demo and get a no-obligation sales quote.

AS650 Model Specifications

Unique Features of the AS650

  TANK CAPACITY

650 gal

CHASSIS, SUSPENSION & TIRES
WEIGHT
(APPROXIMATE DRY WEIGHT)
16,900 lbs
AXLE WIDTH 88″, 90″,108″ 114″ or 120″ fixed

TRANSPORT WIDTH & HEIGHT 144″ maximum
OVERALL LENGTH 290″ minimum
TURNING RADIUS 17′ 2″
WHEEL BASE 13′ 8″
FRONT TIRES (STANDARD) Michelin 380/85R34
REAR TIRES (STANDARD) Michelin 380/80R38
CROP CLEARANCE 42″ or 48″ depending on tire selection
SPRAY OPTIONS
BOOMS

90′, 60/90′ steel

RINSE TANK

50 gal

ENGINE & DRIVETRAIN
RATED HORSEPOWER 163 HP
DRIVELINE EFFICIENCY 90%
PTG: HP PER 1,000 lbs. 8.7
FUEL TANK CAPACITY 80 gal
TRANSMISSION JCB powershift 4-speed
ENGINE Cummins T4F



Want more? Download the full spec sheet.
